Description
[Stall Torque]
51.7kgs (6.6V) / 58.0kgs (7.4V) / 65.8kgs (8.4V)kg・cm
718.4oz (6.6V) / 805.4oz (7.4V) / 914.3oz (8.4V)oz・in
[Speed]
0.15 (6.6V)/0.13 (7.4V)/0.11 (8.4V) Sec/60°
[Weight]
85.5 g / 3.02 in
[diemension]
35 x 20 x 41.5 mm / 1.38 x 0.79x 1.634 in
[Length of lead harness]
300mm
[Operating Voltage]
4.5V – 8.5V
■ programmable: Neutral, endpoint,gain etc(Works with PWM XBUS)120°150°180°(Works with PWM XBUS)Synchronize(Works with PWM XBUS)
■ Super steel full metal gear(Gear B brass)
■ wide valtage
■ BIG upperl ball bearing (12×6) bottom(10×6)
■ Special desigen Brushress motor
